TRYX Panorama 360 White Curved Screen 360mm AIO ndi ROTA PRO 120 White High Performance LCP Case Fan User Manual

1. Zamalonda Zathaview

TRYX Panorama 360 White ndi makina oziziritsira amadzimadzi a All-in-one (AIO) opangidwa kuti azigwira ntchito kwambiri pamakompyuta. Imakhala ndi chophimba chapadera cha 6.5-inchi chopindika pamapampu, chopatsa chiwonetsero cha 2K chokhala ndi mulingo wotsitsimula wa 60Hz pazowonetsa zamphamvu. Wozizira wa AIO uyu ali ndi pampu yamtundu wa Asetek 8th kuti azitha kutentha bwino ndipo amabwera ndi mafani atatu okhazikitsidwa kale a ROTA PRO 120, omwe amadziwika ndi kutuluka kwawo kwa mpweya komanso kuthamanga kwa static, pogwiritsa ntchito masamba a Liquid Crystal Polymer (LCP) kuti azikhala olimba komanso osagwira ntchito. Dongosololi limatha kusinthidwa mwamakonda kwambiri kudzera pa pulogalamu ya TRYX KANALI, kulola kuyang'anira zomwe zili pazenera komanso kuwongolera kwathunthu kwa mafani.

Chithunzi 1.1: The TRYX Panorama 360 White AIO madzi ozizira ozizira ndi kuphatikizidwa kwake ROTA PRO 120 fan.

2. Zofunika Kwambiri

• 6.5-inch Curved Screen: Ili ndi chiwonetsero cha 6.5-inch chopindika chokhala ndi 2K resolution ndi 60Hz refresh rate, kupereka anamorphic view zamitundu yosiyanasiyana. Mawonekedwe a skrini owoneka ngati L amatsimikizira kuwonekera kwathunthu kuchokera kumakona angapo.
• Asetek 8th Gen Pump: Kukonzekera kwapampu kokhala ndi mota yolimba, yokhazikika ya 3-phase, yothandizira mpaka 320W TDP. Mulinso machubu okhuthala 40% ndi radiator ya 30mm yotalikirana kwambiri kuti muzitha kutentha bwino.
• TRYX KANALI Mapulogalamu: Imathandizira kusinthika komaliza ndi zinthu monga Instant Screen Content Switching, Split-Screen Display Capability, Kujambulitsa Mwachangu, ndi Kuwongolera Kwamafani. Imathandizira PNG/JPG/GIF/MP4/AVI media (1080P, 500MB maximum).
• Mafani a ROTA PRO 120: Mafani atatu oyikiratu a 120mm okhala ndi masamba a LCP (Liquid Crystal Polymer), opereka mpweya wa 81.32 CFM, 3.66 mmAq static pressure, komanso maphokoso otsika pansi pa 30.97 dB (A) atadzaza. Imakhala ndi FDB kuti ikhale yokhazikika komanso yabata.
• Kugwirizana Kwambiri: Zimaphatikizapo zida zonse zoyika zitsulo zokhazikika pa Intel LGA 1851/1700/1200/1151/1150/1155 ndi AMD AM4/AM5 sockets.

Chithunzi 2.1: Paview Zazinthu zazikulu kuphatikiza chiwonetsero cha 6.5-inch AMOLED, kuziziritsa kwa Asetek 8th Gen, ndi makonda apulogalamu ya KANALI.

Chithunzi 2.2: Tsatanetsatane pa chivundikiro chagalasi chotsutsana ndi glare ndi ukadaulo womatira wowonekera.

3. Kukhazikitsa & Kuyika

3.1 Zamkatimu Phukusi

Onetsetsani kuti zigawo zonse zilipo mu phukusi:

• TRYX Panorama 360 White AIO Liquid Cooler Unit (Pampu yokhala ndi chophimba chophatikizika, Radiator yokhala ndi machubu olumikizidwa kale)
• 3 x ROTA PRO 120 White High Performance LCP Case Fans (yokhazikitsidwa kale pa radiator)
• All-Metal Mounting Hardware Kit (ya Intel ndi AMD)
• Chingwe cha USB cha Kulumikizana kwa Mapulogalamu a KANALI
• Ma Fan ndi Pump Power Cables
• Buku la ogwiritsa (chikalatachi)

3.2 Zofunikira pa System

Onetsetsani kuti makina anu akukwaniritsa zofunikira izi:

• Kugwirizana kwa Socket ya CPU: Intel LGA 1851, 1700, 1200, 1151, 1150, 1155; AMD AM4, AM5.
• Mlandu Wogwirizana: Malo okwanira 360mm radiator (nthawi zambiri pamwamba kapena kutsogolo).
• Magetsi: Zolumikizira mphamvu zokwanira pampu ndi mafani.
• Opareting'i sisitimu: Windows 10/11 ya magwiridwe antchito a KANALI.

3.3 Njira zoyika

Tsatirani masitepe awa ambiri pakuyika. Onaninso zatsatanetsatane mu bukhu lakuthupi kuti mupeze malangizo atsatanetsatane amtundu wanu wa socket wa CPU.

1. Konzani Motherboard: Ikani mbale yakumbuyo yoyenera ndi zoyimirira za socket yanu ya CPU (Intel kapena AMD).
2. Mount Pump Block: Ikani phala lotentha ku CPU (ngati simunayikepo pa mbale yozizira). Ikani chipika cha mpope pa CPU ndikuchiteteza ndi zomangira zomwe zaperekedwa, kuwonetsetsa kupanikizika.
3. Ikani Radiator: Kwezani radiator ya 360mm yokhala ndi mafani omwe adayikidwiratu pamalo omwe akupezeka pa PC yanu (mwachitsanzo, pamwamba kapena kutsogolo). Onetsetsani kuti mayendetsedwe oyenera a mpweya ayende.
4. Lumikizani Zingwe:
   • Lumikizani chingwe chamagetsi chapampu kumutu wa CPU_FAN kapena AIO_PUMP pa bolodi lanu.
   • Lumikizani zingwe zamphamvu za mafani (kuchokera kwa mafani a ROTA PRO 120) kupita pamutu pamutu panu kapena chowongolera.
   • Lumikizani chingwe cha USB kuchokera pa mpope kupita kumutu wamkati wa USB 2.0 pa bolodi lanu. Izi ndizofunikira pamapulogalamu a KANALI.
5. Kuwongolera Ma Chingwe: Yendetsani zingwe zonse bwino kuti muwonetsetse kuti mpweya ukuyenda bwino m'chombocho.

Chithunzi 3.1: Chithunzi chosonyeza zigawo za pampu ya Asetek 8th Gen, kuphatikizapo micro-convex copper base ndi zitsulo zoyenera.

Chithunzi 3.2: Makulidwe a fani ya ROTA PRO 120, yofunika kuti igwirizane ndi milandu.

4. Malangizo Ogwiritsira Ntchito

4.1 Kuyika Mapulogalamu a KANALI

Kuti mutsegule zonse za TRYX Panorama 360 AIO yanu, tsitsani ndikuyika pulogalamu ya TRYX KANALI kuchokera ku TRYX yovomerezeka. webmalo. Tsatirani malangizo a pa sikirini pakuyika.

4.2 Kusintha kwa Screen

Pulogalamu ya KANALI imapereka njira zambiri zosinthira makonda a 6.5-inchi yopindika:

• Kusintha kwa Instant Screen Content: Sinthani mosavuta pakati pa zowonetseratu zomwe zidakonzedweratu kapena zomwe mumakonda.
• Chiwonetsero cha Gawani-Skrini: Gwiritsani ntchito chophimba chooneka ngati L kuti muwonetse zinthu ziwiri zosiyana nthawi imodzi.
• Kukwezera Zofalitsa: Kwezani zithunzi zanu za PNG, JPG, GIF, kapena MP4, mavidiyo a AVI (mpaka 1080P resolution, 500MB file size) kuti musinthe mawonekedwe.
• Kujambula Mwachangu: Lembani okhutira chophimba mwachindunji mapulogalamu.
• Chidziwitso cha System: Yang'anirani kutentha kwa CPU/GPU, kuthamanga kwa mafani, ndi ma metrics ena pakompyuta mwachindunji.
• Zosefera Zogwiritsa: Ikani zowoneka ngati 'Mvula' kapena 'Smoky' pazithunzi kuti muzitha kulumikizana bwino.

Chithunzi 4.1: Mawonekedwe a mapulogalamu a KANALI omwe akuwonetsa zosankha zazithunzi, kuphatikiza mawonekedwe azithunzi zonse / zogawanika ndi kufananiza ndi media.

Chithunzi 4.2: Mapulogalamu a KANALI omwe akuwonetsa kugawanika kwa skrini ndi kuthekera kowonetsa chidziwitso chadongosolo.

Chithunzi 4.3: KANALI software showcasing zosefera zowonetsera ngati 'Mvula' ndi 'Smoky'.

4.3 Kuwongolera Mafani

Pulogalamu ya KANALI imaperekanso chiwongolero chokwanira pa mafani a ROTA PRO 120 ndi wophatikizika wa VRM:

• Kusintha Kuthamanga kwa Mafani: Khazikitsani kuthamanga kwa mafani pamanja kapena sankhani kuchokera ku pro wofotokozedwa kalefiles (mwachitsanzo, Low Speed, Mid Speed, High Speed).
• Njira Yokongola: Konzani ma curve otengera makonda kutengera kutentha kwa CPU kuti muzizizira bwino komanso phokoso.
• VRM Fan Control: Sinthani mawonekedwe ophatikizika a 60mm VRM okhala ndi mitundu yothamanga anayi komanso ma curve othamanga kuti aziziziritsa Vol ya boardboardtage Regulator modules.

Chithunzi 4.4: mawonekedwe a pulogalamu ya KANALI yowongolera fani ya VRM, kuphatikiza mawonekedwe anzeru ndi ma curve othamanga.

5. Kusamalira

Kusamalira nthawi zonse kumatsimikizira kuti TRYX Panorama 360 AIO yanu ikugwira ntchito bwino komanso kuti ikhale ndi moyo wautali:

• Kuyeretsa Fumbi: Nthawi ndi nthawi muzitsuka fumbi lochokera ku zipsepse za rediyeta ndi masamba akufanizira pogwiritsa ntchito mpweya woponderezedwa kapena burashi yofewa. Kuchulukana kwa fumbi kungalepheretse kuyenda kwa mpweya komanso kuchepetsa kuzizira bwino.
• Kuyang'ana Mafani: Yang'anani ma fan blade ngati pali zopinga zilizonse kapena zizindikiro za kutha. Onetsetsani kuti mafani akuzungulira momasuka komanso mwakachetechete.
• Tubing ndi kugwirizana: Yang'anani machubu ngati akuphulika, akutuluka, kapena kuwonongeka. Onetsetsani kuti zolumikizira zonse (mphamvu, USB) ndizotetezedwa.
• Zosintha pa Mapulogalamu: Sungani pulogalamu ya KANALI kuti ikhale yaposachedwa kwambiri kuti mupindule ndikusintha kwa magwiridwe antchito, zatsopano, ndi kukonza zolakwika.

6. Mavuto

Ngati mukukumana ndi zovuta ndi TRYX Panorama 360 AIO yanu, tchulani zovuta ndi mayankho awa:

• Sikirini Yosawonetsa Zinthu:
  • Onetsetsani kuti chingwe cha USB chochokera pa mpope ndicholumikizidwa bwino ndi mutu wamkati wa USB 2.0 pa bolodi lanu.
  • Tsimikizirani kuti pulogalamu ya KANALI yakhazikitsidwa ndikugwira ntchito.
  • Yang'anani kusamvana kulikonse kwa madalaivala kapena zosintha zamapulogalamu. Yesani kukhazikitsanso pulogalamu ya KANALI.
• Kutentha Kwambiri kwa CPU:
  • Tsimikizirani kuti chingwe champhamvu chapampu ndicholumikizidwa kumutu wolondola wa boardboard (CPU_FAN kapena AIO_PUMP) ndikulandila mphamvu.
  • Onetsetsani kuti chipika chapampu chili bwino pa CPU yokhala ndi phala lokwanira komanso kuthamanga kokwera.
  • Onetsetsani kuti mafani a radiator akuzungulira ndikuwongolera bwino kuti mpweya uziyenda bwino (kukankha kapena kukoka mpweya kudzera pa radiator).
  • Tsukani fumbi lililonse pa zipsepse za radiator.
• Mafani Osapota Kapena Kupanga Phokoso Lachilendo:
  • Tsimikizirani kuti zingwe zamphamvu za fan ndizolumikizidwa bwino ndi mitu ya boardboard kapena chowongolera cha fan.
  • Yang'anani masinthidwe a liwiro la fan mu pulogalamu ya KANALI kapena BIOS kuti muwonetsetse kuti sanakhazikitsidwe ku 0 RPM.
  • Yang'anani mafani ngati ali ndi vuto lililonse.
  • Ngati fan ikupanga phokoso lambiri, zitha kuwonetsa vuto. Lumikizanani ndi chithandizo ngati phokoso likupitilira.
• Mapulogalamu a KANALI Osazindikira Chipangizo:
  • Onetsetsani kuti chingwe cha USB chochokera pampopi cholumikizidwa ndi mutu wamkati wa USB 2.0.
  • Yesani kuyambitsanso kompyuta yanu.
  • Ikaninso pulogalamu ya KANALI.
  • Yang'anani zoikamo za BIOS pa bolodi lanu la mavabodi kuti musinthe doko la USB.

7. Zofotokozera

8. Chitsimikizo & Thandizo

Zogulitsa za TRYX zimapangidwa mwapamwamba kwambiri ndipo zimathandizidwa ndi chitsimikizo cha wopanga. Pazachidziwitso ndi zikhalidwe zinazake, chonde onani khadi la chitsimikizo lomwe lili ndi malonda anu kapena pitani ku TRYX yovomerezeka. webmalo. Ngati mukufuna thandizo laukadaulo, kuthetsa mavuto, kapena muli ndi mafunso okhudzana ndi malonda anu, chonde lemberani chithandizo chamakasitomala a TRYX kudzera munjira zawo zovomerezeka. Onetsetsani kuti muli ndi nambala yanu yachitsanzo komanso zambiri zogulira mukamalumikizana ndi chithandizo.

Kuti mudziwe zambiri ndi chithandizo, pitani ku malo ogulitsira a TRYX: TRYX Amazon Store
